Fully Automatic Dry Mortar Production Line
Dry-mixed mortar, also known as dry-mixed mortar, refers to a granular or powdered mixture produced by a specialized manufacturer, which is a mixture of dried and screened fine aggregate inorganic cementitious materials, water-retaining thickening materials, mineral admixtures and additives in a certain proportion.
Product Introduction
Dry mortar, also known as dry-mixed mortar, refers to a granular or powdery mixture made from a blend of dried and screened fine aggregate inorganic binders, water-retaining thickening materials, mineral admixtures, and additives in certain proportions, produced by specialized manufacturers. Generally speaking, it is primarily composed of yellow sand, cement, thickening powder, fly ash, and admixtures, such as early-strength agents and quick-drying agents, which are added according to specific product requirements.
It can be transported to the construction site in packaged or bulk form, and after mixing with water in the specified ratio, it can be used directly. This machine uses a high-efficiency double-shaft blade mixer, which does not destroy the original state of the materials and ensures that the insulation coefficient of the mortar is not reduced due to the damage of the shape of the insulation materials, thus guaranteeing the insulation effect of the product.
At present, dry mortar is developing rapidly abroad. To implement the national policy on building a conservation-oriented society and to enforce the construction energy-saving regulations that prohibit on-site mixing, dry-mixed mortar has become the new round of investment focus, and fully automatic dry-mixed mortar equipment has quickly become the mainstream product in the market.
Components of the Dry Mortar Mixer
The dry mortar mixing equipment mainly consists of the storage tank, double-shaft agravic mixer, elevator, pre-mixing chamber, small material silo, finished product storeroom, packing scale, bucket elevator, dust collector, fully automatic metering and batching case, electrical control cabinet, and the gas phase balance system framework.
1. Precise metering and batching system
2. Efficient mixing system
3. Environment-friendly and precise packaging system and bulk technology
4. Intelligent computer batching system
5. Complete configuration of dry mortar mixing equipment:
Applicable Mortar Types
First, adhesive mortar, mainly including tile adhesives, sealants, and adhesive mortar specially used for heat insulation composite systems;
Second, plastering mortar, such as interior & exterior wall coating mortar, putty, color decoration mortar, and insulation mortar;
Third, masonry mortar, including common masonry mortar, special thin-bed mortar for concrete blocks, and insulation masonry mortar;
Fourth, floor mortar, such as common floor mortar and self-leveling mortar;
Fifth, special mortar, including repair mortar, waterproof mortar, and hardening powder.
Product Parameters
Model |
TDSJ2 | TDSJ3 | TDSJ4 | TDSJ6 | TDSJ10 |
Comment |
Production capacity (tons/hour) |
10-15 | 15-20 | 20-40 | 40-60 | 60-80 |
Customizable |
Main engine motor (kw) |
18.5 | 22 | 22 | 45 | 55 |
Customizable |
Aggregate size (mm) |
0〜4.75 | 0〜4.75 | 0〜4.75 | 0〜4.75 | 0〜4.75 |
Customizable |
Aggregate scale (kg) |
(200〜1000)±1% | (200〜1500)±1% | (200〜2000)±1% | (400〜3000)±1% | (400〜4000)±1% |
Customizable |
Cement scale (kg) |
(100〜600)±1% | (100〜700)±1% | (100〜800)±1% | (200〜1300)±1% | (200〜1800)±1% |
Customizable |
Addition amount (kg) |
(5〜30)±0.5% | (10〜40)±1% | (10〜50)±0.5% | (10〜200)±0.5% | (10〜200)±0.5% |
Customizable |
